Specifications
Adjustable Armrests |
Yes |
Adjustable Backrest |
No |
Adjustable Seat Height |
No |
Adjustable Tiller Angle |
Yes |
Adjustable Tiller Height |
No |
Anti-Tip Mechanism |
Yes |
Armrests |
Yes |
Battery |
12V 22Ah x 4 |
Battery Range |
37km (extension available) |
Charger |
Automatic Off Board 5Ah |
Controller |
Rhino 2 DS 90 |
Dimensions |
1195 x 620 |
Dimensions when folded |
1260mm x 590mm x 515mm |
Distance between armrests |
460mm-660mm |
Drive Wheel |
250mm |
Foot Room |
710mm |
Front Height |
1050mm |
Front Wheel |
260mm |
Ground Clearance |
750mm |
High / Low Speed Selection |
No |
Lights |
Yes |
Lithium Battery |
No |
Maximum Speed |
6.4km/h |
Mirrors |
No |
Motor |
250W 2-Pole |
Number of Components |
1 |
Seat Dimensions |
410mm x 400mm |
Seat height from Deck |
420mm |
Seat height from Floor |
710mm |
Seat Padding |
Medium |
Slope ability |
6 degrees with 175kg loading 4degrees with 200kg load |
Suspension |
No |
Swivel Seat |
No |
Tiller Angle |
0°-95° |
Total Height |
1010mm |
Total Length |
126mm |
Total Width |
590mm |
Turning Radius |
1020mm |
Tyres |
Pneumatic |
Weight Capacity |
159kg |
Weight with Battery |
116.5kg |
Wheel to Wheel |
770mm |
