- Liftboy 5
- Suitable for indoor and outdoor use
- Suitable for commercial and residential use
- Available in a range of different options
- Available in a range of different colours
- Choose from a gate or access ramp
Add to Product Comparison
- Check out the displays in our showrooms
- Access to parts, servicing and trained technicians
- Comprehensive warranty
Videos
Product Description
The Liftboy 5 was created to lift a wheelchair and a passenger safely up and down levels that reach up to 1300mm in height and has a loading capacity of 300 kg. This lift offers glass inserts in the upper gate and sidewalls and features an overall modern design. If required, this vertical lift can be equipped with a platform gate.
Suitable for commercial properties, private homes as well as public buildings, this lift suits virtually any projects requirements due to its versatility, aesthetics, ease of use, reliable performance and its range of optional finishes.
The Liftboy 5’s entry ramp folds up as a back door once the user is sitting comfortably on the platform. The folded door prevents the user from rolling backwards and falling off the lift. The ramp uses two scissor lifts to rise, which are both protected and unseen on all four sides. The lifts controls are on a stand inside the unit and feature easy operating buttons.
ADVANTAGES
1. Indoor and outdoor version
2. Available in a range of colours
3. Gate instead of an access ramp
4. Side 90-degree entry on the lower level
5. Automatic gate openers
6. Shaft enclosure
7. Gravity access ramp
8. 300 kg load capacity
9. Lifts to 1300 mm height
10. Easy to use controls located inside the unit
11. Designed to lift wheelchair user and passenger
Specifications
Total Height |
120mm to 1300mm |
Total Length |
1400mm |
Total Width |
900mm to 1100mm |
Weight Capacity |
300kg |
Speed |
25mm per sec |
